EK Water Blocks EK-Quantum Volume³ FLT 240 D-RGB - Plexi

This next-generation EK-Quantum Volume³ FLT reservoirs build on the success of the existing FLT, flat-style reservoirs further improves compatibility, and simplifies the installation process by implementing additional G1/4“ connection ports.

The reservoir features standard 120mm fan mounting holes for maximum flexibility during the installation. The reservoir is equipped with a total of six G1/4“ ports so that users can choose the most optimal setup for their liquid cooling loops.

These new FLT reservoirs are available in five different sizes 120mm, 240mm, 140mm, 280, and 360mm.

The new Volume³ flat-shaped reservoirs are to revolutionize the way you were thinking about loop building. Since 120mm fan mounting patterns (105mm apart) are the most dominant mounting options inside PC cases these days, these new Volume FLT reservoirs will allow greater flexibility for installation since they don't require drilling of mounting holes on your case. The reservoir is also equipped with additional mounting points on both sides (105mm apart) which can be used with the included steel L-shaped mounting plates. All mounting holes utilize M4 threads with the included screws.

The reservoir is manufactured of premium quality acrylic material, and machined to perfection, while the sealing is performed by a custom-formed high-quality EPDM o-ring. Alongside the reservoir is a black anodized aluminum cover under which the Addressable D-RGB LED strip is placed. Proper LED implementation is one of the main focus points of EK so that there are as few visible "LED hotspots" as possible. The cover is now a standalone piece, easily removable at any time if the LED strip requires any service or replacement.

Technical specifications:

- Size (HxWxT): 138.5 x 128 x 40mm
- Capacity: ~250ml
- D-RGB connector 3-pin 5V digital LED header (Pinout: +5V, D, Blocked, Ground)
- LED Count: 27

Enclosed:

- EK-Quantum Volume³ FLT 240
- Mounting mechanism with all necessary screws
- L-shaped steel holders with mounting screws

Made in Slovenia - EU!
